Combo: L-Bar w/ Shrink Tunnel
Model No. LST-1616
The LST-1616 is designed for easy and quick shrink wrap packaging. Users can produce products that have a factory fresh clean look and feel. The sealer/tunnel combo creates packages that are free from dust, moisture and fingerprints.
This unique All-In-One L-Bar Sealer and Shrink Chamber is compact and quite the space saver. The shrink tunnel is located underneath the L-bar sealer ensuring a small footprint.
The sealer cuts and seals quick, sharp, and clean. One step cuts and seals film up to 15.7”. Sealing time is controlled by an electric timer. Once seal time is complete, operator places the product underneath in the shrink tunnel to complete shrink wrapping process.
FEATURES
Ideal for quick and easy shrink film packaging
Compact size – shrink tunnel below L-Bar sealer
Max seal width: 15.7”
Sits on casters – easy to move around
220V – Customer provides own plug
Units ships via LTL freight only. Call for freight rates
Specifications:
| x | |
|---|---|
| Power Supply | 220V / 1PH / 20Amps |
| Watts | 4500W |
| Seal Dimensions | 15.7"W x 15.7"L |
| Machine Dimensions | 44"L x 28"W x 44"H |
| Max Film Width | 16" |
| Max Package Height | 6" |
| Production Rate | 6-8PPM |
| Weight (lbs) | 330 |
